MKP-F 交流濾波圓形鋁殼干式系列
| 產品說明： |
|
外徑ΦD（mm） | 間距P（mm） | 接線方式 Connection | 安裝方式 Installation |
Φ76 | 32 | M6銅螺母/M8銅螺栓 | 平底/M12螺栓 |
Φ86 | 32 | ||
Φ96 | 32 | ||
Φ116 | 50 | ||
Φ136 | 50 |
★特點
□高穩定性，可靠性
□具有優良的自愈特性
□能承受較高的紋波電流及峰值電流、電壓
□干式設計，安裝方式靈活
★應用場合
□適用于電力電子設備、變頻器UPS電源、光伏逆變中的交流濾波電路
★技術要求
引用標準 | GB/T17702，IEC61071 | ||
氣候類別 | 40/85/21 | ||
工作溫度范圍 | -40℃～85℃ | ||
存儲溫度范圍 | -40℃～85℃ | ||
電壓范圍 | 400VAC～1000VAC | ||
容量范圍 | 6.8μF～820μF | ||
容量允許偏差 | ±5%（J）/±10%（K） | ||
損耗角正切值 | ≤2×10-3(100Hz，1V，20±5℃) | ||
耐電壓 | 極殼 | 3000V.AC 60S 2Ui+1000V.AC | |
極間 | 1.75Un（60S，20±5℃） | ||
絕緣電阻 | IR×Cn≥5000S(at20±5℃ 100V.DC 60S) | ||
最高使用海拔 | 2000m | ||
最大電極扭距 | M6：5N·m | M8：6N·m | |
平均壽命 | After 60 000 hours at Urms、fN、 50℃ I△C/CI≤3% | ||
最大安裝扭距 | 10Nm | ||
備注：如果海拔使用高度超過2000m，應該考慮海拔對對流冷卻和外絕緣的影響
★技術參數
400V/450VAC | |||||||
Cn (μF) | Dimension | Irms@45℃10KHz(A) | ESR1.0KHz (mΩ) | Rth (K/W) | Part number | ||
ΦD (mm) | H (mm) | P (mm) | |||||
50 | 76 | 70 | 32 | 30 | 2.5 | 5.2 | 1GFK650A400--- |
100 | 76 | 95 | 32 | 40 | 2.1 | 4.4 | 1GFK710A400-- |
150 | 76 | 125 | 32 | 40 | 1.5 | 4.0 | 1GFK715A400-- |
200 | 76 | 175 | 32 | 60 | 1.1 | 3.4 | 1GFK720A400-- |
250 | 86 | 175 | 32 | 70 | 1.3 | 3.2 | 1GFK725A400-- |
320 | 96 | 175 | 32 | 80 | 0.9 | 2.8 | 1GFK732A400-- |
350 | 96 | 175 | 32 | 100 | 0.9 | 2.1 | 1GFK735A400-- |
420 | 116 | 175 | 50 | 100 | 0.6 | 1.9 | 1GFK742A400-- |
500V/550VAC | |||||||
Cn (μF) | Dimension | Irms@45℃10KHz(A) | ESR1.0KHz (mΩ) | Rth (K/W) | Part number | ||
ΦD (mm) | H (mm) | P (mm) | |||||
50 | 76 | 70 | 32 | 40 | 2.5 | 5.2 | 1GFK650A500-- |
100 | 86 | 95 | 32 | 50 | 2.1 | 4.4 | 1GFK710A500-- |
180 | 96 | 125 | 32 | 60 | 1.5 | 4.0 | 1GFK718A500-- |
200 | 86 | 175 | 32 | 70 | 1.1 | 3.4 | 1GFK720A500-- |
250 | 96 | 175 | 32 | 85 | 1.3 | 3.2 | 1GFK725A500-- |
350 | 96 | 225 | 32 | 100 | 0.9 | 2.8 | 1GFK735A500-- |
420 | 116 | 145 | 50 | 100 | 0.9 | 2.1 | 1GFK742A500-- |
690VAC | |||||||
Cn (μF) | Dimension | Irms@45℃10KHz(A) | ESR1.0KHz (mΩ) | Rth (K/W) | Part number | ||
ΦD (mm) | H (mm) | P (mm) | |||||
50 | 76 | 95 | 32 | 40 | 2.5 | 5.2 | 1GFK650A690-- |
100 | 76 | 175 | 32 | 60 | 2.1 | 4.4 | 1GFK710A690-- |
200 | 96 | 225 | 32 | 70 | 1.5 | 4.0 | 1GFK720A690-- |
250 | 116 | 175 | 50 | 80 | 1.1 | 3.4 | 1GFK725A690-- |
300 | 116 | 225 | 50 | 100 | 0.9 | 2.8 | 1GFK730A690-- |
420 | 136 | 225 | 50 | 100 | 0.9 | 2.1 | 1GFK742A690-- |
400V/450VAC | |||||||||
Cn (μF) | Dimension | Irms (A) | ESL (nH) | ESR 1.0KHz(mΩ) | Rth (K/W) | Part number | |||
ΦD (mm) | H (mm) | P (mm) | φd (mm) | ||||||
3×110 | 116 | 130 | 43.3 | 50 | 3×50 | 100 | 3×1.8 | 4.5 | 1GFK711A400-- |
3×145 | 116 | 145 | 43.3 | 50 | 3×60 | 110 | 3×1.75 | 3.8 | 1GKF7145A400-- |
3×175 | 116 | 210 | 43.3 | 50 | 3×75 | 120 | 3×1.75 | 3.5 | 1GFK7175A400-- |
3×200 | 136 | 225 | 52 | 60 | 3×85 | 125 | 3×1.6 | 2.1 | 1GFK720A400-- |
500V/550VAC | |||||||||
Cn (μF) | Dimension | Irms (A) | ESL (nH) | ESR 1.0KHz(mΩ) | Rth (K/W) | Part number | |||
ΦD (mm) | H (mm) | P (mm) | φd (mm) | ||||||
3×100 | 116 | 180 | 43.3 | 50 | 3×45 | 100 | 3×1.8 | 4.5 | 1GFK710A500-- |
3×120 | 116 | 145 | 43.3 | 50 | 3×50 | 110 | 3×1.75 | 3.8 | 1GFK712A500-- |
3×125 | 136 | 180 | 52 | 60 | 3×75 | 120 | 3×1.65 | 3.5 | 1GFK7125A500-- |
3×135 | 136 | 225 | 52 | 60 | 3×80 | 130 | 3×1.6 | 2.1 | 1GFK7135A500-- |
690VAC | |||||||||
Cn (μF) | Dimension | Irms (A) | ESL (nH) | ESR 1.0KHz(mΩ) | Rth (K/W) | Part number | |||
ΦD (mm) | H (mm) | P (mm) | φd (mm) | ||||||
3×49 | 116 | 225 | 43.3 | 50 | 3×60 | 120 | 3×2.2 | 2.1 | 1GFK645A690-- |
3×55.7 | 136 | 225 | 52 | 60 | 3×60 | 130 | 3×2.1 | 3.8 | 1GFK6557A690-- |
850VAC | |||||||||
Cn (μF) | Dimension | Irms (A) | ESL (nH) | ESR 1.0KHz(mΩ) | Rth (K/W) | Part number | |||
ΦD (mm) | H (mm) | P (mm) | φd (mm) | ||||||
3×41.9 | 116 | 225 | 43.3 | 50 | 3×60 | 120 | 3×2.2 | 2.1 | 1GFK645A690-- |
3×55.7 | 136 | 225 | 52 | 60 | 3×80 | 130 | 3×1.85 | 1.8 | 1GFK6557A690-- |
